LGRP® X FURITEK MICRO KOMODO BRUSHLESS MOTOR

Introducing the LGRP® X Furitek Micro Komodo Brushless Motor, a groundbreaking collaboration between Little Guy Racing Parts and Furitek, a renowned name in electronics for RC crawlers. This motor is designed to deliver everything you could ever want for crawling, offering massive low-end torque and exceptionally smooth power and torque curves.

Key Features:

• 12 Pole Hi-Torque Motor Design: Delivers unmatched power and performance.
• Super Thin (0.2 mm) Stator Laminations: Enhances efficiency and reduces heat build-up.
• Japanese NMB High RPM ABEC5 Bearings: Ensures smooth and reliable operation.
• Precision Balanced Rotor: Provides the best reliability and maximum RPM.
• CNC Machined 6061 T6 Billet Aluminum Heatsink Can: Offers superior heat dissipation and durability.
• Precision Engineered for Maximum Energy Conversion: Optimizes performance for demanding RC crawling applications.
• High Purity and Higher Temperature Single Copper Windings: Ensures excellent efficiency and reliability.
• Excellent Heat Dissipation: Maximizes efficiency and prolongs motor life.

Specifications:

• KV (RPM/Motor): 3450
• No-load Current @10V: 0.7A
• Watt: 120W
• Battery: 2-3S
• Resistance: 0.16 Ohms
• Max Current: 10A
• Slot/Pole: 12
• Motor Size (mm): 15.5x20.6
• Shaft (mm): 1.5x6
• Weight (g): 17.5
• Bolt pattern spread: 9mm


What's Included:

• (1) Brushless Motor
• (3) M2 x 10mm Mounting Screws
• (1) .3 mod 12t Brass Pinion Gear

Please note: The LGRP® X Furitek Micro Komodo Brushless Motor is only compatible with motor mounts with a 9mm bolt spread. It is not compatible with the stock SCX24™ motor plate or stock ESC. We highly recommend pairing this motor with the Furitek Lizard Pro 30A/50A ESC and our MR24 Transmission for optimal performance.

This product does not contain and any batteries of any kind.

“WARNING: This product may contain chemicals known to the State of California to cause cancer.” WARNING: This product can expose you to chemicals including arsenic, which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.”
