LGRP® MICRO KOMODO BRUSHLESS KIT FOR TRX4M™

Introducing the LGRP® X FURITEK Micro Brushless kit for the TRX-4M™, engineered to take your crawler to the next level with unmatched performance. This system features the Micro Komodo 1212 3450KV brushless motor, offering an ideal balance of lightweight design and powerful low-end torque for crawling. Paired with the Lizard Pro ESC, it ensures ultra-smooth operation with zero cogging.

The system is designed for a seamless, drop-in installation on the TRX-4M™, and it’s fully compatible with the stock battery. With the addition of Furitek’s FURICAR app and Bluetooth module, you can effortlessly fine-tune settings while on the go, making real-time adjustments to suit your preferences without even touching the truck.

Key Features:

• Compact and lightweight Micro Komodo brushless motor for a low center of gravity, mirroring the stock setup
• High-performance 30A/50A brushless ESC with advanced FOC (Field Oriented Control) technology
• Built-in Bluetooth module for wireless setup and configuration
• CNC-machined brass 11T pinion for durability and precision
• Incredible low-speed crawling torque
• Ultra-smooth operation with no cogging
• Fully compatible with the stock battery
• Lifetime FREE firmware updates

Included in the Package:

• 1 x LIZARD PRO 30A/50A Brushless ESC with FOC Technology and protective case
• 1 x Male TRX4M™ to 2 PIN JST-PH Conversion Cable
• 1 x Integrated Bluetooth module
• 1 x Micro Komodo Brushless Motor
• 1 x 11T CNC Steel Pinion

Motor Features & Specs:

• 12-pole high-torque motor design for exceptional efficiency
• Ultra-thin stator laminations (0.2 mm) to reduce eddy losses and maximize power conversion
• Premium Japanese NMB bearings for superior RPM performance
• Precision-balanced rotor for enhanced reliability and maximum RPM
• CNC-machined 6061 T6 aluminum heatsink for optimal heat dissipation
• High-purity copper windings for reduced losses and efficient cooling

Motor Specifications:

• KV Rating: 3450 RPM
• No-load current (at 10V): 0.7A
• Maximum power: 120W
• Battery: 2-3S LiPo
• Resistance: 0.16 Ohms
• Max Current: 10A
• Motor Dimensions: 15.5mm x 20.6mm
• Shaft Size: 1.5mm x 6mm
• Weight: 17.5g

ESC Features & Specs:

• Compatible with both sensorless brushless and brushed DC motors (configured via app, default is brushless)
• FOC technology for smooth, precise control
• Plug-and-play setup for FMS FCX24 crawlers
• Adjustable BEC: 5V or 6.5V 2.5A (via app configuration)
• Supports 2S-3S LiPo batteries
• Simple, user-friendly app programming for both Android and iOS
• Firmware updates available with Bluetooth module
• Real-time telemetry up to 10Hz

ESC Specifications:

• Supports 2S-3S LiPo batteries
• BEC: 5V or 6.5V 2.5A (no extra BEC required for large servos)
• Continuous current: 30A
• Burst current: 50A
• Built-in power switch
• Built-in Bluetooth module
• Dimensions: 28mm (L) x 15.5mm (W)
• Weight: 3.7g
